- Excellent: Impinj E710 chip with UHF more than 15m reading distance.
- Powerful: Android 9.0 OS, MTK MT6765 Octa-core 2.3GHz
- Humanist: hand grip ergonomic design, lightweight
- Industrial IP65 rugged, 1.2M Drop to concrete, applying to kinds of severe environment
- Long Read Distance ＞ 15M
- Different communication interfaces (WiFi, Bluetooth, 4G, USB)
- Small Inventory App for direct use Free demo, sample code, SDK
- Support Tag search & data filtering
| Specifications | |
|---|---|
| Performance Characteristics | |
| Processor | MTK MT6762 Octa-core(4×A53 2.0Ghz, 4×A53 1.5Ghz) |
| OS | Android 9.0 |
| Memory | 64 GB ROM+4 GB RAM |
| Display | 5.46” HD+ 720×1440 |
| Standard I/O Port | Type-C USB |
| Expansion Slot | 1 Micro SD Slot, 2 SIM Slots |
| Notification | Indicator LED, Speaker |
| Network Characteristics | |
| WIFI | 802.11a/ac/b/g/n (2.4G+5G) |
| WWAN | GSM(B2/B3/B5/B8) / CDMA/CDMA-EVDO: BC0 |
| WCDMA: B1/B8 / TD-SCDMA: B34/B39 | |
| TDD-LTE: B34/B38/B39/B40/B41 / FDD-LTE: B1/B3/B8 | |
| Bluetooth | 5 |
| USB | Type C |
| UHF RFID | |
| Protocol | ISO/IEC 18000-6B, ISO/IEC18000-6C / EPC C1G2 / C2V2 |
| Reading Distance | 0~ ≥15m(According to Tag & Environment) |
| Antenna | Circular 4dBi |
| RF output | 0-33dBm adjustable |
| Frequency | EU: 865-868MHz (ETSI EN 302 208) |
| Other frequency & standard optional | |
| Data Capture & Data Processing Device | |
| Camera | Rear: 13.0MP(PDAF)+Flash led |
| Front: 5.0MP(FF) | |
| Barcode Engine | 2D Imager Barcode Scanner |
| (Support 1D&2D code scan) | |
| Positioning | GPS/AGPS/Glonass/BeiDou, with internal Antenna |
| Environmental Parameters | |
| Storage Temp. | 40℃～+85℃ |
| Operating Temp. | -20℃～+70℃ |
| Humidity | 5% RH～95%RH (non-condensing) |
| Drop Spec. | 1.2M Drop to concrete |
| Dust & Water Proof | IP65 |
| Physical Characteristics | |
| Dimensions | Full set: 164mm(L)×99mm(W)×148.5mm(H) |
| Weight | N.W.: 630g |
| G.W.:1Kg | |
| Battery | Lithium Polymer 10,000mAh(Rechargeable) |
| Accessories | Power Adaptor: Input AC100V ~ 240V / Output DC 9V 2A |
